ACE-C10 4500kg 2 Post Hoist Clear Floor

4500kg capacity
Dual hydraulic cylinders
High quality aluminium pump
WorkCover design registered



Quick Quote

1. My driveway is sealed with an even surface
2. There is reasonable vehicle access with height clearance.
3. I acknowledge the delivery is to the front door, carport, or closest practical delivery point as deemed by the driver.

Available in Brisbane, Sydney, and Melbourne. Please call 0755365269 for a freight quote and ordering.

> 4500kg capacity clear floor premium two post car hoist.

> Full length posts.

> High grade aluminium pump, for a long service life.

> Super Symmetric arms for wider space to open car door.

> Single point release.

Complies with AS1418.9 and WorkCover design registration


Max lift capacity: 4500kg

Height to top of column: 3900mm

Distance between posts: 2558mm

Overall width: 3420mm

Lift height: 1900 mm

Minimum height 100mm

Screw lifting pads plus adapters

Time required to lift from bottom to top: 45~60seconds

Time required from top to bottom: 30~40 seconds

Motor: 240v single phase or 415V 3 phase

Pressure Rating: 19 MPA

Packing Dimensions

395 cm x 60cm x 105 cm, Wgt 690kg

Weight 690 kg
Dimensions 395 × 60 × 105 cm
